Detailed Description
NEW 2024 John Deere 1023E. Yanmar 3 Cylinder Liquid Cooled Diesel Engine.
Engine HP 22.4 (16.5 kW),
PTO HP 14.5 (11.4 kW).
Rated Speed 3200 RPM.
Indirect Fuel Injection.
Glow Plug Cold Starting Aid.
Dry Type Air Cleaner With Safety Element.
Fully Enclosed Engine and Muffler With Horizontal Exhaust.
5.6 Gallon Fuel Tank Capacity (21.2 L).
Hand Throttle.
Key Engine Shut Off.
TRANSMISSION:
Hydrostatic Transmission: Infinitely Variable - 2 Speed Transaxle.
Twin Touch Pedals and Direction Control.
Differential Lock.
FRONT/REAR AXLE:
Flanged Rear Axle.
Spur Gear Final Drive.
4WD STEERING AND BRAKES:
Hydrostatic Power Steering.
Wheel Brakes.
Park Brake.
Wet Disk Brakes.
HYDRAULICS:
Open Center Hydraulic System.
Hydraulic Pump - Total Flow 6.3 GPM (24 L/min) with Filter.
Working Pressure (2000 PSI).
Dual Mid SCV Standard.
PTO:
Mid PTO Standard Equipment.
Independent Mid and Rear PTO.
540-RPM Rear PTO.
Hydraulic PTO Clutch.
PTO Brake.
Separate or Simultaneous Operation of Mid and Rear PTO.
Flip Up PTO Shield.
ROCKSHAFT, 3-PT. HITCH, AND HITCH PLATE:
Rockshaft.
Limited Category 1, 3-Pt. Hitch.
Rate of Drop/Stop Valve.
Hitch Plate.
INSTRUMENTATION:
Fuel Gauge.
Tachometer/Hour Meter.
Oil Pressure Indicator Light.
Coolant Temperature Light.
Alternator Indicator Light.
Flashing Warning Light Indicator.
ELECTRICAL:
12-Volt Electrical System.
Wet Battery With 500 Cold Cranking Amps
40 Amp Alternator
Key Ignition Starter With Neutral Start Switch
LIGHTS:
Two Front Halogen Head Lights
Two Flashing Warning Lights
OPERATOR PROTECTIVE STRUCTURE:
Folding ROPS (Roll-Over Protective Structure)
** Meets SAE J2194 and OSHA
1928 ROPS Certification Standards
Seat Belt
Operator Presence System
MISCELLANEOUS:
Front Weight Bracket
Tilt-Up Hood
Cupholder - Left Console
Mower Deck Height Adjustment
BASE MACHINE (4WD):
Engage on the go 4WD
26x12-12 (4PR, R4 Industrial, 1 Position) Rear Wheels & Tires
18x8.50-10 (4PR, R4 Industrial, 1 Position) Front Wheels & Tires
Tier IV EPA Emissions Certified
Engine HP 22.4 (16.5 kW), PS
PTO HP 14.5 (11.4 kW)
Rated Speed 3200 RPM
MID-MOUNT LIFT SYSTEM:
Mid-Mower Mechanical Lift Ready
Includes Mid-Mower Lift Rockshaft
Includes Mechanical Lift Arm Linkage
**RESIDENCY RESTRICTIONS APPLY**
Additional Description
Backhoe: No, Cab: No Cab, Front Axle: MFWD, Loader: Yes, Mid Mount Mower: No, Transmission: Hydro,
